1. Signal Processing: Unlocking Insights from Vibration Data¶

Vibration data from rotating machinery is a goldmine of information, but it's hidden in noise and complexity. Signal processing is the key to unlocking this information. Think of it as translating the machine's "language" of vibrations into a clear, understandable message about its health.

We start with the signal itself—a representation of vibration over time, either as a continuous analog wave or a discrete digital sequence. Signal processing then uses various techniques to enhance and analyze this signal:

• Time-domain analysis: Looking directly at the signal's shape over time. Think of it like reading a story—we look for sudden changes, repeating patterns, or unusual spikes.
• Frequency-domain analysis (FFT): Transforming the signal to see its hidden frequencies. This is like musical analysis—we identify the dominant notes (frequencies) that reveal the machine's internal workings and potential problems.
• Filtering: Cleaning up the signal by removing unwanted noise. This is like editing a recording—we remove background noise to hear the main instrument clearly.

By combining these techniques, we can extract crucial features from the vibration data, such as characteristic frequencies associated with specific faults, enabling early detection and diagnosis of problems. This allows for proactive maintenance, preventing costly breakdowns and ensuring operational efficiency. This notebook explores these techniques and how they are applied using [Package Name] to analyze vibration data and improve rotating machinery reliability.

2. Essential Theory¶

2.1 Sampling of Vibration Signals¶

Real-world vibration signals are continuous-time and analog. Digital processing requires sampling—converting the signal into a discrete-time sequence by measuring amplitude at regular intervals determined by the sampling frequency, f_s, with sampling interval T_s = 1/f_s.

2.2 Nyquist-Shannon Sampling Theorem¶

Aliasing is phenomena which causes higher frequencies to appear as lower ones in the sampled data.

To avoid information loss (aliasing), the sampling frequency must be at least twice the maximum frequency present in the signal (f_s ≥ 2f_max). Anti-aliasing filters are used before sampling to remove frequencies above f_max.

2.3 Leakage Error¶

Leakage error arises in frequency spectrum analysis when the analyzed signal's duration is not an integer multiple of its fundamental period. This discontinuity at the observation window's edges causes spectral energy to "leak" into adjacent frequency bins, blurring the true frequency components and distorting their amplitudes.

Windowing techniques (e.g., Hanning, Hamming) mitigate this by smoothly tapering the signal's ends, reducing the discontinuity and minimizing spectral leakage.

2.4 Modulation and Demodulation¶

Modulation modifies a carrier signal's properties using a message signal. In Amplitude Modulation (AM), the modulated signal is: s(t) = A_c[1 + m(t)]cos(2πf_ct), where A_c and f_c are the carrier's amplitude and frequency, and m(t) is the message signal.

In RCM, machine speed variations modulate fault frequencies. Demodulation thecniques (etc. envelope extraction using Hilbert transform) recovers the message signal.

2.5 Frequency Filtering¶

Filtering selectively removes or attenuates specific frequency components. Common filter types include:

• Low-pass filters: Pass frequencies below a cutoff frequency and attenuate higher frequencies.
• High-pass filters: Pass frequencies above a cutoff frequency and attenuate lower frequencies.
• Band-pass filters: Pass frequencies within a specific band and attenuate frequencies outside this band.
• Band-stop filters (notch filters): Attenuate frequencies within a specific band and pass frequencies outside this band.

3. Signal Processing using Damavand¶

Damavand offers two main approaches to process vibration signals:

1. Applying transformations: Damavand facilitates the application of the most frequent signal processing transformations.
2. Fetaure extraction: In addition to the transformations, Damavand also supports the extraction of expert-defined features.

3.1 Transformations¶

3.1.0 Downloading and Mining the MFPT dataset¶

In [1]:

from damavand.damavand.datasets.downloaders import read_addresses, ZipDatasetDownloader
from damavand.damavand.datasets.digestors import MFPT
import pandas as pd

# Downloading the MFPT dataset
addresses = read_addresses()
downloader = ZipDatasetDownloader(addresses['MFPT'])
downloader.download_extract('MFPT.zip', 'MFPT/')

mfpt = MFPT('MFPT/', [
	'baseline_1.mat',
	'InnerRaceFault_vload_1.mat',
	'InnerRaceFault_vload_2.mat',
	'InnerRaceFault_vload_4.mat',
	'InnerRaceFault_vload_7.mat',
	'OuterRaceFault_1.mat',
	'OuterRaceFault_vload_1.mat',
	'OuterRaceFault_vload_2.mat',
	'OuterRaceFault_vload_4.mat',
	'OuterRaceFault_vload_7.mat',
])

# Mining the dataset
mining_params = {
    97656: {'win_len': 16671, 'hop_len': 2000},
    48828: {'win_len': 8337, 'hop_len': 1000},
}
mfpt.mine(mining_params)

# Signal/Metadata split
df = pd.concat(mfpt.data[48828]).reset_index(drop = True)
signals, metadata = df.iloc[:, : - 4], df.iloc[:, - 4 :]

from damavand.damavand.datasets.downloaders import read_addresses, ZipDatasetDownloader from damavand.damavand.datasets.digestors import MFPT import pandas as pd # Downloading the MFPT dataset addresses = read_addresses() downloader = ZipDatasetDownloader(addresses['MFPT']) downloader.download_extract('MFPT.zip', 'MFPT/') mfpt = MFPT('MFPT/', [ 'baseline_1.mat', 'InnerRaceFault_vload_1.mat', 'InnerRaceFault_vload_2.mat', 'InnerRaceFault_vload_4.mat', 'InnerRaceFault_vload_7.mat', 'OuterRaceFault_1.mat', 'OuterRaceFault_vload_1.mat', 'OuterRaceFault_vload_2.mat', 'OuterRaceFault_vload_4.mat', 'OuterRaceFault_vload_7.mat', ]) # Mining the dataset mining_params = { 97656: {'win_len': 16671, 'hop_len': 2000}, 48828: {'win_len': 8337, 'hop_len': 1000}, } mfpt.mine(mining_params) # Signal/Metadata split df = pd.concat(mfpt.data[48828]).reset_index(drop = True) signals, metadata = df.iloc[:, : - 4], df.iloc[:, - 4 :]

3.1.1 Envelope extraction (Hilbert transform)¶

Extracting the envelope of of signals.

In [2]:

from damavand.damavand.signal_processing.transformations import env

# Envelope extraction
signals_env = env(signals)

from damavand.damavand.signal_processing.transformations import env # Envelope extraction signals_env = env(signals)

3.1.2 Frequency spectrum extraction (Fast-Fourier Transform)¶

Applying the Fast-Fourier Transform algorithim to derive frequency domain representation of a set of signals

In [3]:

from scipy.signal.windows import hann
from scipy.signal import butter
from damavand.damavand.signal_processing.transformations import fft

# Defining a window to avoid frequency leakage
window = hann(signals_env.shape[1])
# Defining a bandpass frequency filter to both remove near-DC component and avoid aliasing
freq_filter = butter(25, [5, 23500], 'bandpass', fs = 48828, output='sos')

# Frequency spectra extraction, through FFT
signals_fft = fft(signals, freq_filter = freq_filter, window = window)

from scipy.signal.windows import hann from scipy.signal import butter from damavand.damavand.signal_processing.transformations import fft # Defining a window to avoid frequency leakage window = hann(signals_env.shape[1]) # Defining a bandpass frequency filter to both remove near-DC component and avoid aliasing freq_filter = butter(25, [5, 23500], 'bandpass', fs = 48828, output='sos') # Frequency spectra extraction, through FFT signals_fft = fft(signals, freq_filter = freq_filter, window = window)

3.1.3 Refined frequency range spectrum extraction (ZoomFFT Algorithm)¶

Applying the ZoomFFT algorithm to derive a fine-grained frequency representation in a desired frequency range

In [4]:

from scipy.signal.windows import hann
from scipy.signal import butter
from damavand.damavand.signal_processing.transformations import zoomed_fft

# Defining a window to avoid frequency leakage
window = hann(signals_env.shape[1])
# Defining a bandpass frequency filter to both remove near-DC component and avoid aliasing
freq_filter = butter(25, [5, 23500], 'bandpass', fs = 48828, output='sos')

# Frequency spectra extraction within the range of 0 to 2500 Hz, through zoomed_FFT
signals_ZoomedFFT = zoomed_fft(signals_env, 0, 2500, 2500, 48828, freq_filter = freq_filter, window = window)

from scipy.signal.windows import hann from scipy.signal import butter from damavand.damavand.signal_processing.transformations import zoomed_fft # Defining a window to avoid frequency leakage window = hann(signals_env.shape[1]) # Defining a bandpass frequency filter to both remove near-DC component and avoid aliasing freq_filter = butter(25, [5, 23500], 'bandpass', fs = 48828, output='sos') # Frequency spectra extraction within the range of 0 to 2500 Hz, through zoomed_FFT signals_ZoomedFFT = zoomed_fft(signals_env, 0, 2500, 2500, 48828, freq_filter = freq_filter, window = window)

3.1.4 Time-Frequency representation extraction (Short-Time Fourier Transform)¶

Application of Short-Time Fourier Transform to derive Time-Frequency representation of the inputted signals

In [5]:

from scipy.signal.windows import hann
from scipy.signal import butter
from damavand.damavand.signal_processing.transformations import stft

# Defining a window to avoid frequency leakage (unlike previous transformations, the lenght of the window must match the window_len of the stft)
STFT_window = hann(2400)
# Defining a bandpass frequency filter to both remove near-DC component and avoid aliasing
STFT_freq_filter = butter(25, [5, 23500], 'bandpass', fs = float(metadata.iloc[0, 0]), output='sos')

# Time-Frequency representation extraction using 2400-point long segments and a hop lenght of 200 points.
signals_STFT = stft(signals, 2400, 200, STFT_freq_filter, STFT_window)

from scipy.signal.windows import hann from scipy.signal import butter from damavand.damavand.signal_processing.transformations import stft # Defining a window to avoid frequency leakage (unlike previous transformations, the lenght of the window must match the window_len of the stft) STFT_window = hann(2400) # Defining a bandpass frequency filter to both remove near-DC component and avoid aliasing STFT_freq_filter = butter(25, [5, 23500], 'bandpass', fs = float(metadata.iloc[0, 0]), output='sos') # Time-Frequency representation extraction using 2400-point long segments and a hop lenght of 200 points. signals_STFT = stft(signals, 2400, 200, STFT_freq_filter, STFT_window)

The following cells visualize the same observation, under different transformations.

In [6]:

import seaborn as sns
from matplotlib import pyplot as plt
sns.set()

from damavand.damavand.utils import *

fig, axes = plt.subplots(4, 1, figsize = (16, 10))

sns.lineplot(ax=axes[0], x=range(len(signals.iloc[0,:])), y = signals.iloc[0,:])
axes[0].set_title("Original Time Signal")
axes[0].set_ylabel("Amplitude")
axes[0].set_xlabel("sample")
axes[0].set_xlim(0, 8337)

sns.lineplot(ax=axes[1], x=range(len(signals_env.iloc[0,:])), y = signals_env.iloc[0, :])
axes[1].set_title("Envelope")
axes[1].set_ylabel("Amplitude")
axes[1].set_xlabel("sample")
axes[1].set_xlim(0, 8337)


sns.lineplot(ax=axes[2], x = fft_freq_axis(8337, 48828), y = signals_fft.iloc[0, :])
axes[2].set_title("FFT")
axes[2].set_ylabel("Amplitude")
axes[2].set_xlabel("Frequency (Hz)")
axes[2].set_xlim(0, 24424)


sns.lineplot(ax=axes[3], x = zoomed_fft_freq_axis(0, 2500, 2500), y = signals_ZoomedFFT.iloc[0, :])
axes[3].set_title("Zoomed FFT")
axes[3].set_ylabel("Amplitude")
axes[3].set_xlabel("Frequency (Hz)")
axes[3].set_xlim(0, 2500)


plt.subplots_adjust(hspace = 0.75)
fig.show()

import seaborn as sns from matplotlib import pyplot as plt sns.set() from damavand.damavand.utils import * fig, axes = plt.subplots(4, 1, figsize = (16, 10)) sns.lineplot(ax=axes[0], x=range(len(signals.iloc[0,:])), y = signals.iloc[0,:]) axes[0].set_title("Original Time Signal") axes[0].set_ylabel("Amplitude") axes[0].set_xlabel("sample") axes[0].set_xlim(0, 8337) sns.lineplot(ax=axes[1], x=range(len(signals_env.iloc[0,:])), y = signals_env.iloc[0, :]) axes[1].set_title("Envelope") axes[1].set_ylabel("Amplitude") axes[1].set_xlabel("sample") axes[1].set_xlim(0, 8337) sns.lineplot(ax=axes[2], x = fft_freq_axis(8337, 48828), y = signals_fft.iloc[0, :]) axes[2].set_title("FFT") axes[2].set_ylabel("Amplitude") axes[2].set_xlabel("Frequency (Hz)") axes[2].set_xlim(0, 24424) sns.lineplot(ax=axes[3], x = zoomed_fft_freq_axis(0, 2500, 2500), y = signals_ZoomedFFT.iloc[0, :]) axes[3].set_title("Zoomed FFT") axes[3].set_ylabel("Amplitude") axes[3].set_xlabel("Frequency (Hz)") axes[3].set_xlim(0, 2500) plt.subplots_adjust(hspace = 0.75) fig.show()

In [7]:

import numpy as np
from damavand.damavand.utils import fft_freq_axis

t = np.linspace(0, 0.1707, 30)
f = fft_freq_axis(2400, 48828)

fig, ax = plt.subplots(figsize = (16, 8))

ax = sns.heatmap(signals_STFT[0, :, :], xticklabels = np.round(f, decimals = 2), yticklabels = np.round(t, decimals = 2), annot = False, cbar = False)
ax.set(xlabel = 'Frequency (Hz)', ylabel = 'Time (sec)')
ax.set_title('STFT')
ax.set_xticks(ax.get_xticks()[::30])
ax.set_yticks(ax.get_yticks()[::2])


fig.show()

import numpy as np from damavand.damavand.utils import fft_freq_axis t = np.linspace(0, 0.1707, 30) f = fft_freq_axis(2400, 48828) fig, ax = plt.subplots(figsize = (16, 8)) ax = sns.heatmap(signals_STFT[0, :, :], xticklabels = np.round(f, decimals = 2), yticklabels = np.round(t, decimals = 2), annot = False, cbar = False) ax.set(xlabel = 'Frequency (Hz)', ylabel = 'Time (sec)') ax.set_title('STFT') ax.set_xticks(ax.get_xticks()[::30]) ax.set_yticks(ax.get_yticks()[::2]) fig.show()

3.2 Feature Extraction¶

Hand-crafted features (from both time and frequency domains) are widely used for rotating machinery conidition monitoring. Damavand, facilitates the extraction of such features from raw (time and frequency) data.

Features must be implemented as a Python function; then, they must be passed as key-vlaue pairs of "feature_name": (feature_function, (args), (kwargs)) to the feature_extractor function, alongside the signal bank.

The following section, demonstrate the extraction of both time and frequency domains, respectively.

3.2.1 Time-domain Features¶

In [8]:

from damavand.damavand.signal_processing.feature_extraction import *
from numpy import mean, std
from scipy.stats import skew, kurtosis

# Defining the desired features (below is a wide set of time-domain features)
time_features = {
  'mean': (mean, (), {}),
  'std': (std, (), {}),
  'smsa': (smsa, (), {}),
  'rms': (rms, (), {}),
  'peak': (peak, (), {}),
  'skew': (skew, (), {}),
  'kurtosis': (kurtosis, (), {}),
  'crest_factor': (crest_factor, (), {}),
  'clearance_factor': (clearance_factor, (), {}),
  'shape_factor': (shape_factor, (), {}),
  'impulse_factor': (impulse_factor, (), {}),
}

# Extracting the features from the signals
time_features_df = feature_extractor(signals, time_features)
time_features_df

from damavand.damavand.signal_processing.feature_extraction import * from numpy import mean, std from scipy.stats import skew, kurtosis # Defining the desired features (below is a wide set of time-domain features) time_features = { 'mean': (mean, (), {}), 'std': (std, (), {}), 'smsa': (smsa, (), {}), 'rms': (rms, (), {}), 'peak': (peak, (), {}), 'skew': (skew, (), {}), 'kurtosis': (kurtosis, (), {}), 'crest_factor': (crest_factor, (), {}), 'clearance_factor': (clearance_factor, (), {}), 'shape_factor': (shape_factor, (), {}), 'impulse_factor': (impulse_factor, (), {}), } # Extracting the features from the signals time_features_df = feature_extractor(signals, time_features) time_features_df

Out[8]:

	mean	std	smsa	rms	peak	skew	kurtosis	crest_factor	clearance_factor	shape_factor	impulse_factor
0	-0.233352	1.843121	0.699720	1.857834	30.15747	-0.550328	39.490115	16.232595	43.099347	1.891972	30.711608
1	-0.234489	1.720509	0.692389	1.736415	30.15747	-0.538847	36.334443	17.367663	43.555657	1.814836	31.519462
2	-0.234101	1.901948	0.708425	1.916301	32.18819	-0.751920	47.621448	16.797046	45.436280	1.924807	32.331076
3	-0.235983	1.797137	0.686839	1.812564	32.18819	-0.626101	44.018940	17.758374	46.864249	1.891778	33.594892
4	-0.234448	1.800635	0.690554	1.815833	32.18819	-0.547199	43.198745	17.726401	46.612102	1.883161	33.381664
...	...	...	...	...	...	...	...	...	...	...	...
1107	-0.156233	1.504572	0.716416	1.512662	16.14121	0.375640	14.036173	10.670731	22.530485	1.610511	17.185332
1108	-0.157083	1.534541	0.723250	1.542560	16.14121	0.404746	14.021135	10.463912	22.317611	1.621624	16.968533
1109	-0.157834	1.468633	0.713651	1.477090	16.14121	0.327941	13.254681	10.927712	22.617794	1.586590	17.337794
1110	-0.159280	1.455467	0.711277	1.464156	16.14121	0.284900	13.136450	11.024239	22.693293	1.581841	17.438593
1111	-0.160429	1.499163	0.724039	1.507723	16.14121	0.253219	13.184033	10.705689	22.293274	1.594859	17.074060

1112 rows × 11 columns

3.2.2 Frequency-domain Features¶

In [9]:

from scipy.signal.windows import hann
from scipy.signal import butter
from numpy import mean, var
from scipy.stats import skew, kurtosis
from damavand.damavand.signal_processing.feature_extraction import *
from damavand.damavand.utils import *

# Applying the FFT to transform data into frequency-domain
window = hann(signals.shape[1])
freq_filter = butter(25, [5, 12500], 'bandpass', fs = 25600, output='sos')
signals_fft = fft(signals, freq_filter = freq_filter, window = window)

# Extracting frequency axis, as it is essential for some of the features
freq_axis = fft_freq_axis(8337, 48828)

# Defining the desired features (below is a wide set of frequency-domain features)
freq_features = {
  'mean': (mean, (), {}),
  'var': (var, (), {}),
  'skew': (skew, (), {}),
  'kurtosis': (kurtosis, (), {}),
  'spectral_centroid': (spectral_centroid, (freq_axis,), {}),
  'P17': (P17, (freq_axis,), {}),
  'P18': (P18, (freq_axis,), {}),
  'P19': (P19, (freq_axis,), {}),
  'P20': (P20, (freq_axis,), {}),
  'P21': (P21, (freq_axis,), {}),
  'P22': (P22, (freq_axis,), {}),
  'P23': (P23, (freq_axis,), {}),
  'P24': (P24, (freq_axis,), {}),
}

# Extracting the features from the frequency domain signals (assuming that frequency domain signals are stored in signals_fft)
freq_features_df = feature_extractor(signals_fft, freq_features)
freq_features_df

from scipy.signal.windows import hann from scipy.signal import butter from numpy import mean, var from scipy.stats import skew, kurtosis from damavand.damavand.signal_processing.feature_extraction import * from damavand.damavand.utils import * # Applying the FFT to transform data into frequency-domain window = hann(signals.shape[1]) freq_filter = butter(25, [5, 12500], 'bandpass', fs = 25600, output='sos') signals_fft = fft(signals, freq_filter = freq_filter, window = window) # Extracting frequency axis, as it is essential for some of the features freq_axis = fft_freq_axis(8337, 48828) # Defining the desired features (below is a wide set of frequency-domain features) freq_features = { 'mean': (mean, (), {}), 'var': (var, (), {}), 'skew': (skew, (), {}), 'kurtosis': (kurtosis, (), {}), 'spectral_centroid': (spectral_centroid, (freq_axis,), {}), 'P17': (P17, (freq_axis,), {}), 'P18': (P18, (freq_axis,), {}), 'P19': (P19, (freq_axis,), {}), 'P20': (P20, (freq_axis,), {}), 'P21': (P21, (freq_axis,), {}), 'P22': (P22, (freq_axis,), {}), 'P23': (P23, (freq_axis,), {}), 'P24': (P24, (freq_axis,), {}), } # Extracting the features from the frequency domain signals (assuming that frequency domain signals are stored in signals_fft) freq_features_df = feature_extractor(signals_fft, freq_features) freq_features_df

/content/damavand/damavand/signal_processing/feature_extraction.py:103: RuntimeWarning: invalid value encountered in sqrt
  return np.mean(np.sqrt(np.subtract(freq_axis, spectral_centroid(spectrum, freq_axis))) * spectrum) / np.sqrt(P17(spectrum, freq_axis))

Out[9]:

	mean	var	skew	kurtosis	spectral_centroid	P17	P18	P19	P20	P21	P22	P23	P24
0	0.018065	0.000212	1.426027	2.114200	11053.444596	796.261629	12540.952280	2.935690e+08	0.731940	0.072037	2.205723	125.363550	0.035847
1	0.016538	0.000166	1.440692	2.510849	11015.384364	790.490364	12614.367865	3.038027e+08	0.723718	0.071762	2.306647	130.261142	0.033860
2	0.015911	0.000163	1.544936	2.872723	10796.428140	779.206239	12438.754858	3.016914e+08	0.716136	0.072173	2.514890	136.998907	0.032348
3	0.016080	0.000178	1.584992	2.905862	10532.076594	767.281209	12146.457376	2.907104e+08	0.712393	0.072852	2.662891	142.330173	0.031666
4	0.017501	0.000236	1.647699	2.950443	10594.040230	773.264096	12099.593080	2.786391e+08	0.724853	0.072990	2.140161	136.694506	0.034301
...	...	...	...	...	...	...	...	...	...	...	...	...	...
1107	0.015128	0.000206	2.559033	10.592382	9658.153861	723.161190	11307.004650	2.685357e+08	0.689996	0.074876	3.546391	158.120703	0.029296
1108	0.014921	0.000198	2.563811	11.058002	9697.088412	723.418752	11362.562278	2.705444e+08	0.690807	0.074602	3.459591	157.621090	0.029264
1109	0.014107	0.000178	2.703421	13.286557	9592.960582	712.859411	11315.835834	2.738293e+08	0.683828	0.074311	3.729962	165.473946	0.027922
1110	0.013595	0.000168	2.972876	16.970993	9487.339448	700.212027	11228.315022	2.738700e+08	0.678488	0.073805	4.045796	173.713123	0.026819
1111	0.013689	0.000173	3.137925	19.340805	9503.659572	696.582752	11214.560026	2.722860e+08	0.679625	0.073296	4.115159	175.286662	0.026755

1112 rows × 13 columns

3.2.3 catch-22 Feature Set¶

Authors of this study introduce a feature set that not only provide strong classification performance over a wide range of time series dataset, but also are minimally redundant. Using the official implementation of the authors under the hood, the catch22_features function extract this feature set.

In [11]:

from damavand.damavand.datasets.downloaders import read_addresses, ZipDatasetDownloader
from damavand.damavand.datasets.digestors import MFPT
from damavand.damavand.signal_processing.feature_extraction import *
from damavand.damavand.signal_processing.transformations import fft
from damavand.damavand.utils import *
from zipfile import ZipFile
import pandas as pd

# Downloading the MFPT dataset
addresses = read_addresses()
downloader = ZipDatasetDownloader(addresses['MFPT'])
downloader.download_extract('MFPT.zip', 'MFPT/')

mfpt = MFPT('MFPT/', [
	'baseline_1.mat',
	'InnerRaceFault_vload_1.mat',
	'InnerRaceFault_vload_2.mat',
	'InnerRaceFault_vload_4.mat',
	'InnerRaceFault_vload_7.mat',
	'OuterRaceFault_1.mat',
	'OuterRaceFault_vload_1.mat',
	'OuterRaceFault_vload_2.mat',
	'OuterRaceFault_vload_4.mat',
	'OuterRaceFault_vload_7.mat',
])

# Mining the dataset
mining_params = {
    97656: {'win_len': 16671, 'hop_len': 2000},
    48828: {'win_len': 8337, 'hop_len': 1000},
}
mfpt.mine(mining_params)

# Signal/Metadata split
df = pd.concat(mfpt.data[48828]).reset_index(drop = True)
signals, metadata = df.iloc[:, : - 4], df.iloc[:, - 4 :]

# Toggle the include_additionals to False, to stay with the original 22 features
catch22_features_df = catch22_features(signals, include_additionals=True)
catch22_features_df

from damavand.damavand.datasets.downloaders import read_addresses, ZipDatasetDownloader from damavand.damavand.datasets.digestors import MFPT from damavand.damavand.signal_processing.feature_extraction import * from damavand.damavand.signal_processing.transformations import fft from damavand.damavand.utils import * from zipfile import ZipFile import pandas as pd # Downloading the MFPT dataset addresses = read_addresses() downloader = ZipDatasetDownloader(addresses['MFPT']) downloader.download_extract('MFPT.zip', 'MFPT/') mfpt = MFPT('MFPT/', [ 'baseline_1.mat', 'InnerRaceFault_vload_1.mat', 'InnerRaceFault_vload_2.mat', 'InnerRaceFault_vload_4.mat', 'InnerRaceFault_vload_7.mat', 'OuterRaceFault_1.mat', 'OuterRaceFault_vload_1.mat', 'OuterRaceFault_vload_2.mat', 'OuterRaceFault_vload_4.mat', 'OuterRaceFault_vload_7.mat', ]) # Mining the dataset mining_params = { 97656: {'win_len': 16671, 'hop_len': 2000}, 48828: {'win_len': 8337, 'hop_len': 1000}, } mfpt.mine(mining_params) # Signal/Metadata split df = pd.concat(mfpt.data[48828]).reset_index(drop = True) signals, metadata = df.iloc[:, : - 4], df.iloc[:, - 4 :] # Toggle the include_additionals to False, to stay with the original 22 features catch22_features_df = catch22_features(signals, include_additionals=True) catch22_features_df

Out[11]:

	DN_HistogramMode_5	DN_HistogramMode_10	CO_f1ecac	CO_FirstMin_ac	CO_HistogramAMI_even_2_5	CO_trev_1_num	MD_hrv_classic_pnn40	SB_BinaryStats_mean_longstretch1	SB_TransitionMatrix_3ac_sumdiagcov	PD_PeriodicityWang_th0_01	...	DN_OutlierInclude_n_001_mdrmd	SP_Summaries_welch_rect_area_5_1	SB_BinaryStats_diff_longstretch0	SB_MotifThree_quantile_hh	SC_FluctAnal_2_rsrangefit_50_1_logi_prop_r1	SC_FluctAnal_2_dfa_50_1_2_logi_prop_r1	SP_Summaries_welch_rect_centroid	FC_LocalSimple_mean3_stderr	DN_Mean	DN_Spread_Std
0	-1.132135	0.378111	0.818324	2	0.021987	0.713018	0.931262	16.0	0.000533	3	...	-0.051337	0.155494	7.0	2.165575	0.62	0.24	1.254029	1.280226	-0.233352	1.843231
1	-1.212156	0.405717	0.838842	2	0.015240	0.417357	0.935940	17.0	0.000571	4	...	-0.093559	0.184471	8.0	2.165307	0.30	0.88	1.243675	1.265813	-0.234489	1.720612
2	-1.630546	-0.113629	0.789737	2	0.021483	1.812335	0.929822	17.0	0.000723	3	...	-0.027228	0.149193	8.0	2.167602	0.34	0.88	1.273971	1.274452	-0.234101	1.902062
3	-2.033294	-0.458779	0.778984	2	0.016595	1.561510	0.930422	17.0	0.000541	3	...	0.009116	0.167291	8.0	2.168096	0.32	0.82	1.315772	1.257946	-0.235983	1.797245
4	-2.030197	-0.458741	0.780336	2	0.015508	1.673901	0.929343	17.0	0.000431	3	...	-0.011875	0.177576	8.0	2.164446	0.26	0.68	1.318840	1.251895	-0.234448	1.800743
...	...	...	...	...	...	...	...	...	...	...	...	...	...	...	...	...	...	...	...	...	...
1107	-0.677851	0.316727	1.157365	2	0.037245	0.167977	0.947937	19.0	0.001133	3	...	-0.024829	0.365049	10.0	2.114870	0.20	0.88	0.918471	1.153364	-0.156233	1.504663
1108	-0.664059	0.311096	1.126916	2	0.037907	0.277817	0.947817	19.0	0.001116	3	...	-0.109872	0.343456	10.0	2.115158	0.24	0.88	0.927291	1.165169	-0.157083	1.534633
1109	-0.693349	0.325568	1.198491	2	0.030415	0.134321	0.947817	19.0	0.001211	3	...	-0.053257	0.394248	10.0	2.112970	0.20	0.12	0.906199	1.136620	-0.157834	1.468721
1110	-0.698628	0.329506	1.190782	2	0.029601	0.083865	0.947457	14.0	0.000810	3	...	0.011455	0.392137	10.0	2.119922	0.20	0.12	0.904665	1.134735	-0.159280	1.455554
1111	-0.677498	0.320668	1.171436	2	0.034213	-0.004840	0.948297	14.0	0.000821	3	...	0.031246	0.384824	10.0	2.120204	0.20	0.12	0.915403	1.144036	-0.160429	1.499253

1112 rows × 24 columns

In [ ]:
